text.to.cad

Give your agent CAD superpowers. 100% open source and free.

loading step

Install

npx skills add earthtojake/text-to-cad

Skills

Install the library to give agents focused workflows for CAD, fabrication, robot description files, simulation, and local review.

Skill

  • CAD

    skills/cad

    Creates and edits CAD models from plain-language or image requests, with STEP as the main output along with options to export to STL, 3MF and GLB.

    skills/cad

  • step.parts

    skills/step-parts

    Finds off-the-shelf STEP parts like screws, bearings, motors, and connectors.

    skills/step-parts

  • Engineering Drawing

    skills/engineering-drawing

    Dimensioned engineering drawings from a part, as a PDF: views, hidden lines, dimensions, hole callouts, title block.

    skills/engineering-drawing

  • DXF

    skills/dxf

    Creates 2D DXF drawings like profiles, templates, gaskets, and cut layouts from Python sources or CAD geometry.

    skills/dxf

  • URDF

    skills/urdf

    Writes robot structure files with links, joints, limits, inertials, and meshes.

    skills/urdf

  • SRDF

    skills/srdf

    Adds MoveIt planning groups, end effectors, poses, and collision rules to a URDF.

    skills/srdf

  • SDF

    skills/sdf

    Creates simulator models and worlds with frames, physics, sensors, and lights.

    skills/sdf

  • SendCutSend

    skills/sendcutsend

    Checks DXF and STEP files before upload to SendCutSend.

    skills/sendcutsend

  • DfAM Check

    skills/dfam-check

    Measures mesh printability per process: wall thickness, overhangs, support volume, and build orientation.

    skills/dfam-check

  • DFM

    skills/dfm

    Reviews a part for sheet metal, CNC machining, or injection molding, with measured evidence and the cited rule behind every finding.

    skills/dfm

  • G-code

    skills/gcode

    Slices supported mesh files into validated, printer-profiled FDM .gcode with real slicer CLIs.

    skills/gcode

  • Bambu Labs

    skills/bambu-labs

    Dry-runs, uploads, and cautiously starts local Bambu Lab print jobs from validated .gcode.

    skills/bambu-labs

Plugins

Provider-native plugins are an alternative to installing with the Skills CLI.

Codex
codex plugin marketplace add earthtojake/text-to-cad codex plugin add text-to-cad@earthtojake
Claude Code
claude plugin marketplace add earthtojake/text-to-cad claude plugin install text-to-cad@earthtojake
Grok Build
grok plugin install earthtojake/text-to-cad --trust

Restart your agent if newly installed skills do not appear. The Codex plugin requires Codex 0.142.0 or newer; older versions skip it silently.
